ATA5577 125Khz RFID T5577 Plastic Card With Customer Printing
The memory is a 363-bit EEPROM, which is arranged in 11 blocks of 33 bits each. Each block includes a single Lock bit, which is responsible for write-protecting the associated block. Programming takes place on a block basis, so a complete block (including lock bit) can be programmed with a single command. The memory is subdivided into two page areas. Page 0 contains 8 blocks and page 1 contains 4 blocks. All 33 bits of a block, including the lock bit, are programmed simultaneously
Block 0 of page 0 contains the mode/configuration data, which is not transmitted during regular read operations. Addressing block 0 will always affect block 0 of page 0 regardless of the page selector. Block 7 of page 0 may be used as a write-protection password. Block 3 of page 1 contains the option register, which is not transmitted during regular-read operation. Bit 0 of every block is the lock bit for that block. Once locked, the block (including the lock bit itself) is not re-programmable via the RF field. Blocks 1 and 2 of page 1 contain traceability data and are transmitted with the modulation parameters defined in the configuration register after the opcode “11” is issued by the reader. The traceability data blocks are programmed and locked by Atmel.
The ATA5577 is a contactless read and write identification for applications in the 125khz or 134.2khz frequency band .It has 363-bit EEPROM (11 blocks with 33 bits each ) can be read and written bock-wise from a base station ( reader ) , is designed to be compatible with the T5557 and ATA5567 . T5577 RFID card mainly uses for different applications such as access control , animal ID and waste management . Shenzhen ZhiJie IOT Application Co.,Ltd as the one of leading rfid products manufacturing who has provided high quality printing and good working performance products for our loyalty customers . We also can help you generate 26 or 37 format HID proximity card according to our T5577 rfid plastic card . Customized printing , hot-stamping , embossing , sequentially numbers ,QR barcode ,magnetic strip ,die-cut hole and shape are available .
Description :
All 125KHz~134.2KHz T5577 RFID card will fully complain with ISO 18000-2 and ISO 11784/11785 protocol , normally 125KHz will widely use for acceoss control and 134.2KHz will widely use for animal husbandry management ,Shenzhen ZhiJie IOT Application Co.,Ltd is specializing in different kinds of rfid cards and experienced manufacturers since 2010, any interested products please list your detailed information and get response soon from us .
Product |
ATA5577 125Khz RFID T5577 Plastic Card With Customer Printing |
Material |
PVC, ABS, PET |
Size |
ISO 86*54*0.84mm or customized is available |
Surface Finishing |
Glossy/Matte/Frosted/Transparent |
Printing |
Without printing, with lamination overlay |
Chips Option |
T5577 |
Memory |
363 bits |
Reading distance |
3-8cm |
Personalization |
Serial number, barcode, magnetic stripe, QR code, encoding, etc |
Package |
In smaller white box, then in carton |
Shipment |
By Express, by air, by sea |
Application |
Door control access , identification , hotel card , member card etc . |
Advantage :
Shenzhen ZhiJie IOT Application Co.,Ltd was exprienced rfid products manufacturers China since 2010 , we can help you to produce different kinds of frequency rfid products with 125KHz , 13.56MHz and 860-960MHz passive rfid chip . In our factory we have rfid card workshop , rfid label sticker workshop and some additional crafts card making department such as embossing , magnetic strip , encoding , hot-stamping , barcode ,QC and laboratory testing department . Now we have more 12 sets flip-chip machines and winding antenna machines for meeting large quantities projects for you .
Our advantage as below :
1:ISO size and controlled tollerance in card producing .
2:Excellent printing in plastic rfid card , rfid label or paper rfid cards .
3:Strictly in QC procedures and laboratory testing for keeping stablely feature of rfid products
4: Stablely production time and quanlity gurantee for you
5: RoHS certification and in-time response
More Products Reference :
Applications :
125KHz LF T5577 rfid card mainly uses for door access control , identification , portrait proximity ID card ,etc . You can chose detailed 125khz rfid chip or your requested applications then we can help you to find better solution with rfid card .
Additional Crafts for Cards :
Our card can meet customers'personalization requested .such as barcode , signature panel ,scrath panel ,encoding ,hole punching ,etc . Droping detailed with your cards producing and we are willing to make good services with our esteemed customers .
Package & Shipping Term
We support customer requested shipping term and below specification package will our standard information for reference , final package will depend on certain quantities and size ,shape or another card crafts make right package and carton size . Customized package requested is available .
